MTD-Engines 1 X 65 CU 752Z1X65CU (2015) Short block Spareparts
Short block 752Z1X65CU (2015)
| Pos | Article Number | Description | |
| 1 | 651-05169 | SHORTBLOCK | |
| 89 | 751-14667 | OIL DIPSTICK ASSY | |
| 91 | 731-10209 | OIL FILL TUBE | |
| 95 | 751-11549 | CONTROLLER | |
| 109 | 751-10370 | OIL DRAIN PLUG AND WASHER ASSY | |
| 152 | 751-11741 | CAMSHAFT ASSY. | |
| 153 | 751-14433 | PISTON RING SET | |
| 158 | 3061-M6-0026 | RING-SNAP | |
| 159 | 751-14434 | PISTON | |
| 160 | 751-14435 | PISTON PIN | |
| 161 | 751-14436 | PISTON ROD | |
