DEVILBISS Holegun Sears 13mm 27158 Spareparts

• Start
• DEVILBISS
• Divers
• Holegun Sears 13mm
• 27158
• Seite 1

27158 Holegun Sears 13mm

Pos		Article Number	Description
1		SB-176850-00	ARMATURE 115V
2		SB-176848-00	FIELD 115V
3		SB-176846-02	BRUSH 120V
5		SB-N440281	BRUSH HOLDER,L
6		SB-176800-02	BRUSH HOLDER
7		SB-176830-43	SWITCH
8		SB-330072-98	CORDSET
9		SB-605040-06	BEARING,BALL
10		SB-605040-06	BEARING,BALL
11		SB-449192-00	TERMINAL
13		SB-390005-10	CASE,FIELD
14		SB-395052-00	HANDLE COVER
15		SB-176829-00	CORD CLAMP
16		SB-N918736	CORD PROTECTOR
17		SB-330019-13	SCREW
18		SB-176951-00	SCREW
19		SB-949721-03	SLEEVE
20		SB-176811-00	BAFFLE
21		SB-949638-02	DAMPER
22		SB-395342-00	ID LABEL
23		SB-395343-00	NP: 900.271580
24		SB-176634-02	GEAR CASE
25		SB-176638-00	SPINDLE
26		SB-605040-20	BEARING
27		SB-176691-00	SPACER
28		SB-388761-00	GEARCASE COVER
29		SB-023813-00	WASHER FIBRE
30		SB-176639-00	GEAR
31		SB-99227-05	PIN
32		SB-605256-01	SCREW
33		SB-176640-00	CAP
34		SB-429662-00	1/2 CHUCK & KEY
36		SB-176718-00	BOLT,T-HEAD
39		SB-382272-60	SIDE HANDLE
43		SB-136086-02	TERMINAL
45		SB-330019-14	SCREW
46		SB-176655-00	GASKET
48		SB-87692-00	RETAINER
50		SB-93128-00	BEARING NEEDLE
54		SB-330004-00	BEARING
55		SB-176647-00SV	GEAR & PINION SA
56		SB-91817-00	WASHER THRUST
57		SB-091644-00	BEARING THRUST
58		SB-330019-16	SCREW
62		SB-176860-00	LEADWIRE
63		SB-176834-00	LEAD BLUE
80		SB-330034-03	CHUCK KEY
81		SB-65288-01	HOLDER CHUCK KEY
800		SB-286436-00	GREASE
856		SB-176929-00	CLIP,LOCK-OUT
