J6181F Torque Wr Dial 3/8 Dr 600

Pos		Article Number	Description
1		SB-5140184-34	HANDLE ASSY.
2		SB-5140184-33	MOVEMENT
3		SB-5140184-35	TOP PLATE
4		SB-52-0001	CASE RED PLASTIC - S
5		SB-5140184-47	BEZEL SCREW
8		SB-5140184-50	SCREW
9		SB-5140184-51	FLAT HEAD SCREW
10		SB-5140184-55	SCREW PLASTITE
11		SB-5140184-56	SCREW
13		SB-5140184-60	SHELL
14		SB-5140184-61	SHELL FOLLOWER
15		SB-5140187-82	MODEL SCALE
17		SB-81-1049	SHELL FOLLOWER NEW S
18		SB-81-1059	MEMORY LENS
19		SB-5140184-66	CALIBRATION PLUG
20		SB-5140185-52	POINTER D3
