Spare Parts Lists for Toro Roth / TORO Transmission Assy. No. 66-9030 (Cont.)

Lists

pos.	decription	spare part number
37	Shaft-Output	62-1080
38	Bushing-Flange	62-1170
39	Washer -Thrust	257-10
40	Shaft-Intermediate	62-0330
41	Gear-Compound 19T/41T	62-0360
42	Gear-51T	62-0260
43	Gear-33T	62-0210
44	Gear Case-Lower	62-0480
45	Bushing-Yoke	29-9570
46	Bushing-Intermediate	62-1160
47	Gear-26T	68-4310
48	Gear-15T	62-0500
49	Hex Washer Hd. Thread Forming Screw	12-3270
50	Pulley-Traction	62-1310
51	Flange Locknut	32128-32
52	Hub-Pulley	62-0380
53	Pinion-Bevel 19T	62-0350
54	Capscrew	321-15
55	Sleeve-Shift	68-4320
56	Key-Shift	62-0310
57	Gear-Bevel 36T	67-5870
58	Collar-Shift	67-5880
59	Gear-Bevel Reverse 36T (Incl. Ref.	13-3559
60	Pin-Roll	32121-120
	Graese-14.5 oz. Cartridge	505-101
