| pos. | decription | spare part number | |
| 2 | Pin, Dowel | 27652 |
| 3 | Seal, Oil | 35319 |
| 4 | Plug, Sq. Hd. Pipe, 1/4-18 (Oil Drain) | 27642 |
| 6 | Yoke, Governor | 30700 |
| 7 | Screw, Fil. Hd. | 650494 |
| 8 | Ring, Retaining | 29642 |
| 9 | Clamp, Governor Lever | 29916 |
| 10 | Screw, Hex Washer Hd. | 29826 |
| 11 | Locknut, Hex | 29216 |
| 12 | Screw, Hex Washer Hd. | 650548 |
| 13 | Lever, Governor | 33454 |
| 14 | Lockwasher, E.T. | 29918 |
| 15 | Locknut, Hex | 30322 |
| 16 | Baffle, Blower Housing | 35326 |
| 17 | Screw, Hex Washer Hd. | 650561 |
| 19 | Crankshaft Assy. | 35372 |
| 22 | Piston, Pin & Ring Assy. (Incl. Ref. | 34552 |
| 23 | Ring, Piston Pin Retaining | 27888 |
| 24 | Ring Set, Piston (Std.) | 34332 |
| 24 | Ring Set, Piston (.010 Oversize) | 34333 |
| 24 | Ring Set, Piston (.020 Oversize) | 34334 |
| 26 | Screw, Connecting Rod | 650882 |
| 27 | Dipper, Oil | 35374 |
| 28 | Lifter, Valve | 34034 |
| 29 | Camshaft (Mechanical Compression Release) | 35375 |
| 30 | Gasket, Cylinder cover | *35262 |
| 31 | Cover, Cylinder (Incl. Ref. | 35376 |
| 32 | Bushing, Crankshaft | 35377 |
| 33 | Seal, Oil | 35319 |
| 34 | Shaft, Mechanical Governor | 31845 |
| 35 | Spool, Governor | 30588A |
| 36 | Ring, Retaining | 29193 |
| 38 | Bracket, Governor Gear | 33369 |
| 39 | Screw, Hex Washer Hd. Thread Forming | 650836 |
| 40 | Washer, Flat | 30590A |
| 41 | Screw, Hex Washer Hd. | 650833 |
| 42 | Screw, Hex Washer Hd. | 650832 |
| 45 | Cap, Upper Valve Spring (Exhaust) | 27882 |
| 45 | Seal Assy., Intake Valve | 34689 |
| 46 | Spring, Valve | 27881 |
| 47 | Cap, Lower Valve Spring | 32581 |
| 48 | Screen, Starter | 35446 |
| 49 | Cup, Starter | 35287 |
| 50 | Wire, Ground | 35253 |
| 51 | Key, Flywheel | 32589 |
| 52 | Screw, Hex Washer Spinlock Hd., Thread Forming | 650738 |
| 54 | Washer, Lock | 650880 |
| 55 | Nut, Flywheel | 650881 |
| 56 | Head, Cylinder | 34030 |
| 57 | Gasket, Cylinder Head | *34041 |
| 58 | Screw, Hex Flange Hd. | 6021A |
| 59 | Screw, Special Hex Hd. Tapped | 650727 |
| 60 | Washer, Flat | 650691 |
| 61 | Cover, Cylinder Head | 33272A |
| 63 | Screw, Hex Hd. | 650713 |
| 65 | Spark Plug, Resistor (Champion RJ-19LM) | 35395 |
| 66 | Body, Breather | 28423 |
| 67 | Element, Breather | 28424 |
| 68 | Gasket, Breather Cover | *27896 |
| 69 | Cover, Valve Spring | 28425 |
| 70 | Tube, Breather | 27627 |
| 71 | Screw, Fil. Hd. | 650128 |
| 72 | Gasket, Intake | *27915 |
| 73 | Pipe, Intake | 33877 |
| 74 | Screw, Fil. Hd. | 650378 |
| 75 | Gasket, Carburetor | *33263 |
| 76 | Screw, Fil. Hd. | 30088A |
| 77 | Nut & Lockwasher | 29752 |
| 78 | Line, Fuel | 30705 |
| 79 | Clamp, Fuel Line | 26460 |
| 81 | Control Assy., Speed (Incl. Ref. | 34664 |
| 82 | Screw, Fil. Hd. | 650549 |
| 83 | Spring, Compression | 31342 |
| 84 | Link, Governor | 34667 |
| 85 | Link, Governor Lever-to-Throttle | 33878 |
| 86 | Spring, Speed Control | 34663 |
| 87 | Clip, Conduit | 27793 |
| 88 | Screw, Hex Washer Hd. | 28942 |
| 88 | Screw, Hex Washer Hd. Thread Cutting | 650821 |
